Portable Electric DOT Peen Vin Number Marking Machine

Model

HBS-380D

Marking Area

30mm x 80mm

Marking Pattern

Line, Arc, Angularity, Dot-Matrix

Marking Depth

<=0.3mm (Adjustable with different material)

Marking Hardness

<=HRC62

Marking Speed

2 - 5 Characters Per Second

Power supply

AC220V ±10% 50Hz

COM Port

RS232, USB

Power Consumption

<=350W

HBS-130D - 30mm x130mm HBS-6130D - 60mm x130mm

Dimension(mm)

620X290X460 (marking head: 138X100X50, controller:235X185X190)

Net Weight(kg)

8(machine head: 3.6, controller: 4.4)

Gross Weight(kg)

10

The latest machine developed by the HBS, function without compressed air supply. It's a pioneer product in China with registered patents. The electromagnetic marking can be used anywhere as long as there is power supply. It can be equipped with battery in case of field work. Compared with pneumatic marking systems, noise level is lower.

The portable marking head is ideal choice for marking on large-scale or heavy work pieces which is difficult to move.

Fully off-line operation, user friendly interface, easy to use and simple to operate.

• Automatic marking of Chinese and English characters, running numbers, VIN code, bitmap font, 2D code, etc.
• Marking pin is made of typical hard alloy and marking on products with hardness up to HRC62.
• Anti-interference, strong resistance against radiation and well adapted for harsh environment work.
• Extremely low failure rate, less maintenance
• Low power consumption, low cost, low price
